CS Quiet Screw Compressor 5.5HP with 270L Tank
Starting From: $4495
The CS4-T is a 5.5 HP direct-drive rotary screw compressor delivering 13 CFM at 10 Bar, with ultra-quiet operation (59±3 dBA). Featuring a 270L tank, this energy-efficient and reliable compressor is ideal for applications that require minimal noise and robust performance.
Description
CS Small Range Screw Compressor
The CS4-T is a 5.5 HP direct-drive rotary screw compressor engineered for high-efficiency performance, providing 13 CFM at 10 Bar. With its ultra-quiet operation of 59±3 dBA, it’s the ideal choice for smaller workshops or facilities where minimising noise is just as important as reliable performance. This model features a 270L tank and is perfect for users seeking an energy-efficient, low-maintenance compressor with flexible installation options.
Key Features:
- Power: 5.5 HP / 4 kW direct-drive rotary screw compressor
- Capacity: 13 CFM at 10 Bar working pressure
- Noise Level: Ultra-quiet operation at 59±3 dBA
- Power Supply: 415V three-phase
- Air Outlet: 3/4″
- Dimensions: 1347×540×1480 mm
- Weight: 250 kg
- Tank: Includes 270L tank for consistent performance
- Price:$4,495
Advantages of CS Quiet Screw Compressor
- Direct Drive Technology: The 1:1 coupling between the motor and airend eliminates belt-driven losses, resulting in better efficiency.
- Energy-Efficient Design: Specifically engineered to optimise energy use while maintaining consistent performance.
- Minimal Maintenance: Only periodic oil and filter changes are needed, with no belts to replace.
- Quieter Operation: Operates at 59±3 dBA, perfect for environments that require low noise levels.
- Compact and Versatile: The 270L tank and small footprint make the CS4-T a great choice for tighter spaces
Built for Tough Environments
- Weatherproof and Corrosion-Resistant: Built to handle both indoor and outdoor environments, even in harsh conditions.
- Heavy-Duty Filtration: Equipped with external filter mats designed to manage high dust loads.
- Enhanced Sealing: Protects the compressor from contaminants, ensuring long-lasting, stable performance.
- Air Receivers Comply with AS1210: Ensures the safety and reliability of your air system, meeting Australian standards.
EASY PERFORMANCE TRACKING AND MAINTENANCE
The CS4-T comes with a 6.5-inch LCD touch screen that allows for real-time monitoring of key operating parameters. The intelligent microcontroller helps track the performance of the compressor, provides service reminders, and enables proactive maintenance to minimise downtime.
Key Features:
- Real-Time Monitoring: Continuously monitor pressure, temperature, and current.
- Programmable Control: Set start/stop schedules and adjust settings for better efficiency.
- Service Alerts: Built-in alarms and tracking for timely maintenance.
- Energy-Saving Logic: Optimises the compressor’s energy use based on actual demand.
- Graphical flow diagram
- Operation record/chart display
- Pressure/temperature/overload/overcurrent/phase loss/unbalance protection
- Pre-alarm system to avoid sudden failure
- Fault history
High-Quality European Motor and Airend
- SKF Bearings: Premium quality bearings used in both the motor and airend for durability and smooth operation.
- BSC Rotary Screw Airends: Patented rotors offer high efficiency, low noise, and stable performance under various operating conditions.
- European Teflon Oil Seals: Ensures minimal vibration and low noise, extending the compressor’s service life.
Seamless Steel Bypass System
The seamless steel bypass system ensures an efficient airline installation. It includes a condensate manifold system, saving on installation costs, and allows easy removal of the refrigeration air dryer (when fitted) without interrupting the airflow.
Quietest Industrial Compressor
The CS4-T is one of the quietest industrial-grade compressors in its class. With sound levels comparable to a regular conversation, it is perfect for use in:
- Workshops
- Garages
- Indoor facilities where noise reduction is a priority
Reliable Cooling System for Demanding Conditions
The CS4-T features oversized coolers designed to handle Australian conditions, ensuring effective cooling even in warmer environments. This helps prevent overheating, protecting internal components and extending the service life of the compressor.
MAINTAINING HIGH-QUALITY AIR DELIVERY
The oversized oil separator ensures the compressor delivers clean, dry air, with less than 3 ppm of oil carryover, ensuring high-quality air and optimal compressor efficiency.
Long-Lasting Suction Valve
The suction valve in the CS4-T is rated for over 2 million cycles. Its design eliminates the need for sealing gaps, reducing failure points that can occur with cup seals and diaphragms.
High-Efficiency Air Intake Filtration
The CS4-T uses high-efficiency air intake filtration to ensure the compressor’s intake air remains clean, improving reliability, reducing energy consumption, and extending the compressor’s lifespan.
Warranty
This warranty covers the complete compressor, ensuring peace of mind. Terms and conditions apply.
Additional information
Additional information
| Weight | 250 kg |
|---|---|
| Dimensions | 1347 × 540 × 1480 cm |
